Certifix CFTSC2 timber screws self embedding countersunk head A2 stainless with cutting point 10.0 x 150/80 TX40

£159.00
The Certifix CFTSC2 10.0 x 150/80 TX40 A2 stainless steel screw has a cutting point that reduces splintering, eliminates the need to pre-drill in many standard substrates, and self-embeds with a ribbed countersunk head. It is ETA and UKTA approved, and is suitable for many other substrates.

Certifix CFTSC2 timber screws self embedding countersunk head A2 stainless with cutting point 10.0 x 150/80 TX40 is backordered and will ship as soon as it is back in stock.

Technical Datasheet

Download the technical datatsheet here.

Applications

The CFTSC2 screw is the ideal choice for fastening into wood, with its optimal thread geometry and Torx Drive for maximum power transmission.

Building Materials

Certifications

Features

Countersunk Head: Clean finish.
Stainless steel: For resistance in corrosive environments.
TX internal, multi-tooth drive: Allows, secure, wobble-free,
screw driving from setting to countersinking.
Cutting point: Reduces splintering and need to pre-drill inmany substrates.
Ribs under the countersunk head: Make the screw
self-embedding and allow it to become flush with the
surface for a neat finish.
European Technical Assessment (ETA) & UK Technical Assessment (UKTA): Quality assured.
* Suitable for many other substrates - Testing available.

Specifications
  • Diameter (MM)
    10
  • Type
    Timber screw
  • Thread Length (MM)
    80
  • Pack Size
    100
  • Material
    A2 Stainless Steel
  • Length (MM)
    150
  • Tech Datasheet
    Certifix_CFTSC2_timber_screw_TDS-compressed.pdf
  • Driver Type
    TX40
  • Head Type
    Countersunk
  • Head Diameter (mm)
    19.00
  • Head Height (mm)
    4.70
  • Tensile (N)
    500 N/mm²
  • Tensile N/mm
    500 N/mm²
  • Drive Shape
    Inner multi-tooth

Reviews (0)

Delivery & Returns

Lorem Ipsum Dolor Sit Amet

Safe & Secure

  • Apple Pay
  • Google Pay
  • Maestro
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

We ensure secure processing of your payment information and do not retain or have any access to your credit card details.

Buy now pay later with Shop Pay

Certifix

Certifix CFTSC2 timber screws self embedding countersunk head A2 stainless with cutting point 10.0 x 150/80 TX40

£159.00
The Certifix CFTSC2 10.0 x 150/80 TX40 A2 stainless steel screw has a cutting point that reduces splintering, eliminates the need to pre-drill in many standard substrates, and self-embeds with a ribbed countersunk head. It is ETA and UKTA approved, and is suitable for many other substrates.

Clamping Range (MM)

N/A

Diameter (MM)

10

Drill Diameter (MM)

N/A

Drill Hole Depth (MM)

N/A

Installation Torque (TINST) (NM)

N/A

Washer Height (MM)

N/A

Washer Diameter (MM)

N/A

Type

Timber screw

Torque Moment (NM)

N/A

Thread Length (MM)

80

Thread

N/A

Size

N/A

Pack Size

100

Package Contents

N/A

Material

A2 Stainless Steel

Length (MM)

150

Min Drill Hole Depth for Through Fixings (MM)

N/A

Max Usable Length HEF Stand/HEF Min

N/A

Max Fixture Thickness (MM)

N/A

Width Across Nut (MM)

N/A

Features

Countersunk Head: Clean finish.
Stainless steel: For resistance in corrosive environments.
TX internal, multi-tooth drive: Allows, secure, wobble-free,
screw driving from setting to countersinking.
Cutting point: Reduces splintering and need to pre-drill inmany substrates.
Ribs under the countersunk head: Make the screw
self-embedding and allow it to become flush with the
surface for a neat finish.
European Technical Assessment (ETA) & UK Technical Assessment (UKTA): Quality assured.
* Suitable for many other substrates - Testing available.
